Video Intercom Keypad Module

Features

• Supports unlock the door via entering password
• Supports call the resident via entering room No.
• Backlight compensation
• Easy to and extend

System parameters

• Processor: Embedded MCU Processor
• Operation method: Physical button

Interfaces

• Moduleconnecting: 2 (1 input, 1 output)
• Debug 1

General

• Physical button: 12
• DIP switch: 8
• Power input: 12 VDC (powered by the other module)
• Power output: 12 VDC (powered for the other module)
• Power consumption ≤ 2 W
• Working temperature: -40° C to 55° C(-40° F to 131° F)
• Working humidity: 10% to 95%
• IP protection level: IP65, IK7
• Installation: Flush mounting, surface mounting


  Weight	0.983 lbs
  Dimensions	3.071 × 6.102 × 6.102 in
